Pavilion with Sink

Company & Product Overview

Shandong Duoping New Material Technology Co., Ltd. specializes in the professional R&D, production and supply of pavilion with Sink, and is a strength manufacturer with core process capabilities in this field. Relying on three core processes—aluminum alloy extrusion molding, fluorocarbon spraying, and integrated water guiding system—the company creates Pavilion with Sink that combine efficient drainage, corrosion resistance, durability, aesthetics and practicality. As a preferred material for high-end outdoor leisure and landscape architecture, the products are widely used in villa courtyards, hotels and homestays, municipal parks, commercial plazas and other scenarios. With the advantages of an integrated drainage solution and low maintenance costs, the products serve markets across the country. Adhering to the concept of professional customization, we sincerely look forward to cooperating with all sectors to provide personalized, high-quality one-stop solutions for various outdoor leisure projects.

Core Technical Parameters

Core Product Features

The Pavilion with Sink takes "integrated water guiding + all-round corrosion resistance" as its core advantage. It selects 6063-T5 aerospace-grade aluminum alloy profiles and is equipped with an integrated water guiding channel system, which can realize directional diversion and rapid discharge of rainwater, fundamentally eliminating water accumulation and side leakage on the top. The aluminum alloy material is naturally rust-free, and the surface is treated with fluorocarbon spraying, which has excellent weather resistance and can adapt to harsh outdoor environments such as coastal, humid and high-temperature areas. Compared with traditional steel structure pavilions, the product is lighter in weight, adopts an assembled structure design, requires no on-site welding, greatly improves installation efficiency, and has almost zero later maintenance costs.

Application Scenarios & Adaptation Solutions

The product focuses on the needs of high-end outdoor leisure and landscape construction, and is suitable for multiple scenarios and styles:

Home Decoration Scenarios: Suitable for villa courtyards, private gardens and terrace leisure areas, and can match various residential styles such as new Chinese style, modern minimalist style and European style;

Commercial Decoration Scenarios: Can be used in hotels, homestays, commercial plazas and resorts to meet the functional needs of outdoor reception and leisure entertainment;

Municipal Scenarios: Adapt to parks, scenic spots and urban greenways, effectively improving the quality and practicality of public spaces.

The product can be equipped with LED ambient lights, sunshade louvers, leisure seats and other accessories to optimize the user experience. Customized reinforcement schemes are required for extreme wind and snow environments, and it can be used stably in other conventional outdoor scenarios.

Production Process & Quality Details

The company adopts automated extrusion molding and CNC processing technology throughout the production process, selects high-purity 6063-T5 aluminum alloy, adds additives such as anti-aging agents and UV absorbers, and forms integrated profiles through high-temperature extrusion, with no welding seams and strong structural stability. The core water channel system is integrally formed through precision molds, and the slope of the water guiding channel is accurately controlled at 3°-5° to ensure rapid rainwater diversion. The surface adopts fluorocarbon spraying technology, with a coating thickness of more than 40μm, uniform and full color, strong adhesion and not easy to fall off.

The water channel and the main structure adopt seamless splicing technology to prevent rainwater leakage; the column is equipped with built-in stiffeners to improve the overall wind resistance and adapt to harsh outdoor environments. The production process has no welding and no exhaust emissions, complying with green environmental protection standards; automated production ensures uniform specifications of each batch of profiles, which can meet the needs of large-scale batch projects. The water channel system is reserved with an inspection port for later maintenance and cleaning. All finished products pass multiple tests such as wind resistance, rain resistance and aging resistance before leaving the factory.

Summary of Core Product Advantages

Integrated Efficient Drainage: Precision water guiding channel with directional drainage design, drainage capacity ≥150mm/h, no water accumulation or side leakage in heavy rain, effectively protecting the ground and foundation structure;

All-round Corrosion Resistance & Durability: 6063-T5 aluminum alloy + fluorocarbon spraying process, reaching C5 grade full corrosion resistance standard, no rust, service life of more than 25 years, adapting to various harsh environments;

Assembled Convenient Installation: Light weight, no welding required, professional team can complete the installation of a 3×3m standard Pavilion within 1 day, greatly shortening the construction period;

Low Maintenance Cost: No painting or anti-corrosion treatment required, only clean water flushing is needed for daily use, and the annual maintenance cost is extremely low;

High Customization Degree: Supports full customization of size, shape and color, and can be equipped with a variety of accessories to meet the personalized needs of different scenarios.

Applicable Environment & Style Adaptation

The product is suitable for a wide range of climatic environments, can withstand extreme temperature differences from -40℃ to 70℃, and has the characteristics of moisture resistance, UV resistance and salt spray corrosion resistance. It is suitable for outdoor use in most areas such as rainy southern areas, coastal high-salt spray areas and cold northern areas. For typhoon-prone areas, thickened profiles and reinforced connectors can be customized to improve wind resistance; for areas with many fallen leaves, it is recommended to equip with anti-clogging nets for water channels to reduce debris accumulation and cleaning frequency.

Strong style adaptability: New Chinese style can be matched with anticorrosive wood accessories and carved hanging falls, modern minimalist style can choose solid color coating and simple lines, European style can be equipped with decorative columns and curved ceilings, perfectly integrating into various landscape design systems.

Structural Design & Specification Description

The product adopts an assembled core structure, consisting of columns, beams, ceilings, water guiding channels and accessories. The common specifications are as follows:

Courtyard Leisure Pavilion (3000×3000mm): Column 120×120mm, beam 80×80mm, water guiding channel 50×40mm;

Commercial Reception Pavilion (4000×4000mm): Column 150×150mm, beam 100×100mm, water guiding channel 60×50mm, equipped with LED ambient lights;

Municipal Landscape Pavilion (5000×5000mm): Thickened column 180×180mm, beam 120×120mm, water guiding channel 70×60mm, built-in stiffeners.

Supports non-standard size customization from 3000mm to 8000mm, covering square, hexagonal and octagonal shapes, with colors optional such as white, gray, champagne and dark brown. The installation adopts concrete foundation to fix the columns, and the beams and ceilings are spliced with special connectors without welding; the construction must strictly control the verticality of the columns and the slope of the water channel (3°-5°) to ensure structural stability and drainage efficiency.

Instructions for Use & Precautions

The depth of the concrete foundation during installation shall be ≥300mm to ensure the verticality of the columns and the accurate slope of the water channel, so as not to affect the drainage effect and structural stability;

For daily cleaning, wipe with clean water or neutral detergent, do not use sharp objects such as steel wool to scratch the coating, and regularly clean up fallen leaves and debris in the water channel to prevent clogging;

Regularly check the fastening status of connectors, inspect every six months in coastal and typhoon areas, and replace aging accessories in time to avoid structural loosening;

It is forbidden to hit or climb the pavilion with heavy objects, and it is forbidden to pile debris on the top to prevent structural deformation and water channel damage. It is strictly forbidden to cut and modify the profiles without permission;

Do not use hard objects to knock when removing ice and snow in winter. Surface scratches can be repaired with special aluminum alloy repair agent, and water channel blockage can be cleaned through the inspection port.

Frequently Asked Questions

Q1: Can the drainage capacity of the pavilion with Sink cope with heavy rain?

A: Absolutely. The drainage capacity of the water guiding channel is ≥150mm/h, far exceeding the heavy rain standard in most areas of China. With the precise slope design of 3°-5°, there is no water accumulation or side leakage in heavy rain.

Q2: Will aging and fading occur after long-term outdoor use?

A: The aging and fading speed is extremely slow. The profile is added with anti-aging additives, and the surface is treated with fluorocarbon spraying. It will not fade for 15 years in outdoor use, and the normal service life can reach more than 25 years.

Q3: Does installation require professional personnel?

A: It is recommended to install by a professional team. The construction needs to accurately control the verticality of the columns, the slope of the water channel and the firmness of the foundation. A professional team can complete the installation of a 3×3m standard pavilion in 1 day.

Q4: Does daily maintenance require a lot of effort?

A: No need to spend too much effort. The product requires no painting or anti-corrosion treatment, only clean water flushing is needed for daily use, and regular cleaning of debris in the water channel is sufficient, with extremely low maintenance costs.

Procurement & Customization Services

The company provides one-stop customization and procurement services for Pavilion with Sink, supporting full-dimensional customization of size, shape, color, water channel specification and accessory matching. It can provide exclusive design schemes according to different scenarios and style needs such as home decoration, commercial decoration and municipal use.

Services include free on-site measurement, design and drawing, and technical disclosure; bulk procurement can enjoy substantial discounts, products are packaged with moisture-proof and shock-proof packaging, and national delivery is supported. After-sales service provides a 5-year warranty. During the warranty period, problems such as profile deformation, water channel leakage and accessory aging caused by non-human damage can be repaired and replaced free of charge; lifelong technical consultation and accessory supply services are provided.
